SINGLE-PANEL SAFETY GLASS (ESG)
- Status
- The offer is out of date
- Minimal order
- 1000 m²
- Available quantity
- 1000000 m²
- Country
- Austria
- Grade
- New
- Delivery time
- 14 days
- Last update
- 8 months ago
Current offers in this category
Offer's description
ESG is a thermally toughened single-pane safety glass (ESG) according to EN 12150. In the so-called toughening process, the glass is heated to temperatures above the transformation temperature and then suddenly cooled. The surface cools faster than the core. A tensile stress is created in the core and a compressive stress in the surface. When producing toughened safety glass, all processing (edge processing, drilling, cut-outs, etc.) must therefore be carried out before the tempering process, as subsequent processing is not possible. Processing of toughened glass would lead to breakage of the pane (fracture pattern: small crumbly fragments). The mandatory and permanent marking (tempered) is usually affixed in the corner area of rectangular panes
